Rewinding Machine
| Business Type | Manufacturer, Exporter |
| Model No. | HP-109 |
| Loading Type | Side Loading |
| Max Roll Width | 450mm |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Unnwinding Reel Diameter
400mm
Rewinding Reel Diameter
76mm OD
Speed
150 mtrs/min (max.)
Web Guide Stock
±25mm
Dimension (LxWxH)
1950 x 1580 x 1200
Weight
500kg (Approx.)
Brand
Hi Pack & Fill Machines Private Limited
Technical Specification
| Model No. | HP-109A | HP-109 |
| Loading Type | Centre Loading | Side Loading |
| Max Roll Width | 1000mm | 450mm |
| Unwinding Reel Diameter | 600mm | 400mm |
| Rewinding Reel Diameter | 76mm | 76mm OD |
| Speed | 200mtrs/min (max) | 150mtrs/min (max) |
| Web Guide Stock | 25mm | 25mm |
| Dimension(LxWxH) | 2200mmx1500mmx1200mm | 1950mmx1580mmx1200mm |
| Weight | 750kg (Approx) | 500kg (Approx) |
